Bolt lengths
43.0 mm
-
Bolt threads
M16 x 1.5
-
Calculated Volume (dm³)
3.9239
-
Clamp band
166 mm
-
Clamp band position
20°
-
Distance between bolts
120.6 mm
-
Max. operating pressure
10.2 bar
-
Operating pressure
10.2 bar
-
Output force
6500 N
-
Output force m
6500 N
-
Port (side)
M16 x 1.5
-
Port (top)
M16 x 1.5
-
Port angle
0°
-
Port threads
M16 x 1.5
-
Product category
Device
-
Push-rod length
15 mm
-
Push-rod thread
Ball R8
-
Return-spring force
220 N
-
Stroke
57.0 mm
-
Technical specification
OE specification
-
Temperature range
-40°C to +80°C
-
Total length
121.0 mm
-
Type
14
-
Version
Without boot
-
Size (mm x mm x mm)
183 x 151 x 142
-
UPC
193133249085
-
Weight (kg)
2.86
-
Weight (lb)
6.3052
