Bolt lengths
38.0 mm
-
Bolt threads
M16 x 1.5
-
Calculated Volume (dm³)
3.7034
-
Clamp band
166 mm
-
Clamp band position
90°
-
Distance between bolts
120.6 mm
-
Max. operating pressure
10.0 bar
-
Operating pressure
10.0 bar
-
Output force
7300 N
-
Output force m
7300 N
-
Port (top)
M16 x 1.5
-
Port threads
M16 x 1.5
-
Product category
Device
-
Push-rod length
15 mm
-
Push-rod thread
Ball R8
-
Return-spring force
150 N
-
Stroke
57.0 mm
-
Technical specification
OE specification
-
Temperature range
-40°C to +80°C
-
Total length
450.0 mm
-
Type
16
-
Type of operation
Disc
-
Version
Without boot
-
Size (mm x mm x mm)
167 x 144 x 154
-
UPC
193133480075
-
Weight (kg)
2.9
-
Weight (lb)
6.3934
