Bolt lengths
38.0 mm
-
Bolt threads
M16 x 1.5
-
Calculated Volume (dm³)
4.4778
-
Clamp band
166 mm
-
Clamp band position
180°
-
Distance between bolts
120.6 mm
-
Max. operating pressure
10.0 bar
-
Operating pressure
10.0 bar
-
Opposite
423 104 701 0
-
Output force
6300 N
-
Output force m
6300 N
-
Port (side)
M22 x 1.5
-
Port angle
-90°
-
Port threads
M22 x 1.5
-
Product category
Device
-
Push-rod length
26 mm
-
Push-rod thread
Ball R8
-
Return-spring force
200 N
-
Stroke
73.0 mm
-
Technical specification
OE specification
-
Temperature range
-40°C to +80°C
-
Total length
117.0 mm
-
Type
16
-
Type of operation
Disc
-
Version
Without boot
-
Size (mm x mm x mm)
184 x 144 x 169
-
UPC
193133245759
-
Weight (kg)
3.024
-
Weight (lb)
6.6668
